Vertical Wood Log Band Saw with Log Carriage
- PRODUCT DETAIL
wooden log vertical band saw machine is used to saw wood log to the wood plate. it is an ideal machine for processing precious wood such as large rosewood and sandalwood. automatic bandsaw adopts automatic feeding, automatic discharging and returning design. The fully automatic wood log band saw can not only saw raw materials such as round wood. square wood and semi-circular shape. but also can saw various special-shaped wood. vertical wood log band saw is composed of steel and cast iron pieces. Both ends of the shaft are equipped with a set of bearing boxes. this band saw machine tool has a reasonable design, stable operation, low noise large size of sawn timber, which is widely used in paint brush factory.
The vertical band saw with log carriage has a wide range to wood diameters in sawing. It works by fixing the headrig in a position where the carriage travels in front of it by means of a wire rope or motor driven reciprocation and snaps the logs onto the woodworking carriage to saw into dimensions customer specified. This processing method is convenient and efficient, and how to choose right saw head and carriage based on the different diameters&lengths of the customer’s wood. Meanwhile the traditional carriage can be operated manually, semi-automatically or fully automatically. The way of clamping wood is divided into manual/electric/pneumatic
Features
Saw wheel was made of weld-steel plate with quality protective deck, fixed headrig and balancing system keep sawed wood accurate diametion and smooth surface during cutting.
The linear bearing and tensioning system at the upper/down saw wheel will respond faster and accurately to the changes of saw blade tensioning
Log carriage with series running method-Manual one cheap but durable, automatic one afforable but higher productive is available to all customers, whether you are the person start milling Or professional sawmill factory.
Manual lubrication
Specification of Wood Log Bandsaw
|
Model
|
RM-BS318
|
|
Saw wheel diameter (mm)
|
800mm
|
|
Saw wheel width (mm)
|
100mm
|
|
Saw wheel speed (r/min)
|
720
|
|
Saw wheel length(mm)
|
5600
|
|
Saw width(mm)
|
90-120
|
|
The thickness of the saw blade (mm)
|
0.25-1.25
|
|
Max.throat distance (mm)
|
320
|
|
Motor power (KW)
|
11
|
|
Motor speed (r/min)
|
1450
|
|
Dimensions of saw machine (mm)
|
2600*2000*1200
|
Working Video of Vertical Wood Log Band Sawmill Machine
