Disposable Wooden Forks Production Line
- PRODUCT DETAIL
Disposable Wooden Forks Production Line includes wood plate rotary cutting making machine, Forks shape dies cutting machine, forks teeth making machine and forks shape heat forming machine.
1. Wood Plate Rotary Cutting Making Machine
Double Segment Rotary Cutting Machine applies to process small diameter round wood material. It has a computer controlling system, adjust easily, low noise, easy operation, good rigidity and high efficiency. It is widely used in the wood processing machine. Double Segment Rotary Cutting Machine is a necessary machine for ice cream sticks production line and ice cream spoons production line.
Specification of Wooden Forks Wooden Plate Rotary Cutting Machine
| Model | RM-RDS |
| Wood Board Thickness | 1- 8mm |
| Processing Length | <520mm |
| Clamping Diameter | <800mm |
| Dimension | 2500*2400*1300mm |
| Principal Axis Speed | 0 – 220 r/min |
| Main Motor Power | 7.5 Kw & 1400r/min |
| Moving Forward Motor Power | 1.5 Kw & 1400r/min |
| Auxiliary Clamping Motor Power | 1.5 Kw & 1400r/min |
| Weight | 2350kg |
| Max Cuting Speed | 380mm/s |
Working Video of Forks Wooden Plate Rotary Cutting Machine
2. Forks Shape Die Cutting Machine
Forks Shape Die Cutting Machine is used to cut the wood board into certain size wood chips. The width and thickness of wood chips are adjustable. The wood after rotary cutting is with certain temperatures. You shall process the wood veneer immediately. Generally speaking, if you order 1 set of wood rotary cutting machine, you need 2 sets of the carved cutting machine.
Specification of Forks Shape Die Cutting Machine
| Power | 1.5kw |
| Motor speed | 1440r/min |
| Cutting frequency | 400 times/min |
| Max cutting width | 430mm (customized) |
| Max. cutting layer | 8-9 layers |
| Max. carved cutter No. | 3 pcs cutter |
| Overall Dimension | 1170*1050*1050mm |
| Net Weight | 520kg |
Working Video of Forks Shape Die Cutting Machine
3. Forks Teeth Making Machine
Disposable Wooden Forks Teeth Making Machine is used to make the fork’s teeth. It requires the worker to put the raw fork shape wood plate under the machine. The machine will clamp the material. Then press the start button. The machine will automatically make the teeth.
Working Video of Wooden Forks Teeth Making Machine
4. Forks Shape Heat Forming Machine
Forks Shape Heat Forming Machine (with teeth making function) can make the wooden spoon-shaped plate to the wooden spoon. When it combined with our triple punching cutting machine, it is a wooden spoon production line.
Forks Shape Heat Forming Machine adopts ZYG,pneumatic-hydraulic and adopts compressed air as the power source. When the pressure is confirmed, the pressure will change with the compression area. On this principle, we increase the pressure to very high to get a good effect. Disposable Forks making the machine has the feature of high pressure, low voice and stable working.
Working Video of Wooden Forks Shape Hot Forming Machine
